M28

機架式數字調音臺

M28是一款高性能的3U數字調音臺。前板上配有24個輸入接口，，其中16個通道可以在MIC及LINE之間進行切換；另外8個為1/4”接口的LINE通道。6個AUX輸出通道中，2個可以作為監聽輸出鏡像，另外配有2個主左、右通道。除此以外，在前板上還配置了可調增益大小的耳機1/4”接口，為監聽輸出。將USB閃存盤插入M28前板的USB端口上，可進行USB立體聲或雙通道錄音及回放功能，輸入跟輸出通道可以作為錄音源。

M28由性能強大的MARANI? DSP獨家處理器所驅動，內置如Taps高達1024的FIR（主左/右通道）、效果器、閃避功能、RTA、反饋抑制、自動混音功能等一系列復雜的聲音處理功能，每個輸入跟輸出通道上都有如參數均衡器、RMS壓縮器、可調延時等。另外，每個輸出通道額外配有31段圖示均衡器。用戶可以通過前板上的以太網端口將M28連接到PC軟件上。除此以外，M28內置WIFI模塊，用戶可以通過WIFI將設備與PC聯機，以實時監控當前的參數設置以及對機器進行控制，大大地使現場演出、錄音室等使用場合的操作更加方便。一臺M28可以同時在WiFi狀態下連接4臺PC電腦或iPad，在以太網方式連接10臺PC電腦，任意一臺設備上的設置更改，也會自動更新到其他連接的設備上。另外，用戶可以直接在PC軟件一鍵式進行固件升級。

使用擴展模塊，M28支持額外4個輸入通道的擴充，可選擇為模擬、AES數字或DANTE?


M28是一款高性能的3U數字調音臺。前板上配有24個輸入接口，，其中16個通道可以在MIC及LINE之間進行切換；另外8個為1/4”接口的LINE通道。6個AUX輸出通道中，2個可以作為監聽輸出鏡像，另外配有2個主左、右通道。除此以外，在前板上還配置了可調增益大小的耳機1/4”接口，為監聽輸出。將USB閃存盤插入M28前板的USB端口上，可進行USB立體聲或雙通道錄音及回放功能，輸入跟輸出通道可以作為錄音源。

M28由性能強大的MARANI? DSP獨家處理器所驅動，內置如Taps高達1024的FIR（主左/右通道）、效果器、閃避功能、RTA、反饋抑制、自動混音功能等一系列復雜的聲音處理功能，每個輸入跟輸出通道上都有如參數均衡器、RMS壓縮器、可調延時等。另外，每個輸出通道額外配有31段圖示均衡器。用戶可以通過前板上的以太網端口將M28連接到PC軟件上。除此以外，M28內置WIFI模塊，用戶可以通過WIFI將設備與PC聯機，以實時監控當前的參數設置以及對機器進行控制，大大地使現場演出、錄音室等使用場合的操作更加方便。一臺M28可以同時在WiFi狀態下連接4臺PC電腦或iPad，在以太網方式連接10臺PC電腦，任意一臺設備上的設置更改，也會自動更新到其他連接的設備上。另外，用戶可以直接在PC軟件一鍵式進行固件升級。

使用擴展模塊，M28支持額外4個輸入通道的擴充，可選擇為模擬、AES數字或DANTE?


Audio Characteristics
Input16x Female XLR connectors: usable as MIC and LINE

8x Female XLR connectors:LINE
Extra Input Channels on Extension Card4xTRS Connectors: LINE

4xXLR Connectors: AES

Rj45: DANTE
Output6x Male XLR connectors: AUX (two Selectable as Monitor)

2x Male XLR connectors: MAIN L/R
THD+N<0.004%
S/N RatioMain L/R: 100dB

Monitor: 103dB
Frequency Response20Hz~20kHz; -0.5dBu at 20Hz~20kHz
Ground Noise-93dBu
Max Input GainLINE: +15dBu

MIC: -12dBu
Max Output GainAUX: +15dBu

MAIN L/R: +15dBu


DSP Processing
DSP ProcessingMARANI DSP engine, 24 bit (audio data) x 48 bit (coeff.), 24 x 96 bits resolution on intermediate computation results
Input EQ4 PEQs, selectable as Bell, Lo/Hi-Shelving, or set as the Morph EQ
Output EQMAIN: 8 PEQs + 31 GEQs

AUX: 3 PEQs + 31 GEQs

Filters of the PEQ can be selectable as Bell, Lo/Hi-Shelving
Filter Gain-12 ~ +12dB
Filter Q Factor0.3 ~ 20
Output GainUp to 12dB
HP/LP filter (AUX / MAIN)1st /2nd /3rd /4th order of Butterworth, Linkwitz-Riley, frequency ranging from 20Hz ~ 20kHz (step: 1Hz)
EffectsTypes: Reverb, Delay, Chorus, Flanger, Phaser, Tremolo, Chorus+Tremolo, Flanger+Tremolo, Phaser+Tremolo, Room (small,mid,large)
DuckerThreshold: -56 ~ -12dBfs, step: 1dB

Release Time: 1ms ~ 1s

Attack Time: 1ms ~ 1s

Hold Time: 10ms ~ 1s
Feedback Eliminator (AUX/ MAIN)Displacement Frequency range (Delta F):

2Hz ~ 8Hz
Input Noise GateThreshold from -80dBfs ~ -50dBfs

Attack Time from 1~1000ms;

Release Time from 1~1000ms
RMS CompressorThreshold from -30dBu ~ 0dBu

Ratio: 1:1~32:1, Knee: 0~100%

Attack Time: 1ms ~ 1s

Release Time: 1ms ~ 1s
DelayEach input delay time is up to 15ms

Each MAIN has an up to 150ms delay

Each AUX has a delay time is up to 150ms






General


Preset5
Dimension481x215x132mm
Weight (Net/Shipping)4.0 kg / 4.3 kg


  • Audio Characteristics
    Input16x Female XLR connectors: usable as MIC and LINE

    		8x Female XLR connectors:LINE
    Extra Input Channels on Extension Card4xTRS Connectors: LINE

    		4xXLR Connectors: AES

    		Rj45: DANTE
    Output6x Male XLR connectors: AUX (two Selectable as Monitor)

    		2x Male XLR connectors: MAIN L/R
    THD+N<0.004%
    S/N RatioMain L/R: 100dB

    		Monitor: 103dB
    Frequency Response20Hz~20kHz; -0.5dBu at 20Hz~20kHz
    Ground Noise-93dBu
    Max Input GainLINE: +15dBu

    		MIC: -12dBu
    Max Output GainAUX: +15dBu

    		MAIN L/R: +15dBu


    DSP Processing
    DSP ProcessingMARANI DSP engine, 24 bit (audio data) x 48 bit (coeff.), 24 x 96 bits resolution on intermediate computation results
    Input EQ4 PEQs, selectable as Bell, Lo/Hi-Shelving, or set as the Morph EQ
    Output EQMAIN: 8 PEQs + 31 GEQs

    		AUX: 3 PEQs + 31 GEQs

    		Filters of the PEQ can be selectable as Bell, Lo/Hi-Shelving
    Filter Gain-12 ~ +12dB
    Filter Q Factor0.3 ~ 20
    Output GainUp to 12dB
    HP/LP filter (AUX / MAIN)1st /2nd /3rd /4th order of Butterworth, Linkwitz-Riley, frequency ranging from 20Hz ~ 20kHz (step: 1Hz)
    EffectsTypes: Reverb, Delay, Chorus, Flanger, Phaser, Tremolo, Chorus+Tremolo, Flanger+Tremolo, Phaser+Tremolo, Room (small,mid,large)
    DuckerThreshold: -56 ~ -12dBfs, step: 1dB

    		Release Time: 1ms ~ 1s

    		Attack Time: 1ms ~ 1s

    		Hold Time: 10ms ~ 1s
    Feedback Eliminator (AUX/ MAIN)Displacement Frequency range (Delta F):

    		2Hz ~ 8Hz
    Input Noise GateThreshold from -80dBfs ~ -50dBfs

    		Attack Time from 1~1000ms;

    		Release Time from 1~1000ms
    RMS CompressorThreshold from -30dBu ~ 0dBu

    		Ratio: 1:1~32:1, Knee: 0~100%

    		Attack Time: 1ms ~ 1s

    		Release Time: 1ms ~ 1s
    DelayEach input delay time is up to 15ms

    		Each MAIN has an up to 150ms delay

    		Each AUX has a delay time is up to 150ms






    General


    Preset5
    Dimension481x215x132mm
    Weight (Net/Shipping)4.0 kg / 4.3 kg
